PRI-4050-M Primary Vacuum Table for alu and engineering plastics milling
Product Details:
- Equipment Type Primary Vacuum Table
- Usage Clamping of thin sheet metal and engineering plastics in CNC machining
- Material Other
- Size 400*500*48
- Processing Type Standard
- Height 48 Millimeter (mm)
- Condition New
- Click to view more
X
PRI-4050-M Primary Vacuum Table for alu and engineering plastics milling Price And Quantity
- 100 Piece
- Anti-vibration Rubber Legs
- Optional In-built Heating (upto 120C)
- Heavy Duty Copper Wound Motor
- Perforated Stainless Steel Sheet
- Integrated with Easy Switch Controls
- Floor Standing
- Low Noise Operation (<75 dB)
- Inlet and Outlet Air Ducts
- Approx. 100-150 kg
PRI-4050-M Primary Vacuum Table for alu and engineering plastics milling Product Specifications
- Blue
- 400 Millimeter (mm)
- -0.08~-0.1 mpa
- 750 Watt (W)
- Vacuum clamping system
- 1 year
- Pneumatic
- Not applicable
- 220-240V/50Hz or 415V/3 Phase (optional) Volt (v)
- New
- Clamping of thin sheet metal and engineering plastics in CNC machining
- 400*500*48
- CNC machining and Precision engraving
- 36 Kilograms (kg)
- 48 Millimeter (mm)
- Other
- Other
- Automatic vacuum liquid separator and vacuum pump
- Anodizing
- Standard
- Primary Vacuum Table
- 500 Millimeter (mm)
- 400*500*48 Millimeter (mm)
- Anti-vibration Rubber Legs
- Optional In-built Heating (upto 120C)
- Heavy Duty Copper Wound Motor
- Perforated Stainless Steel Sheet
- Integrated with Easy Switch Controls
- Floor Standing
- Low Noise Operation (<75 dB)
- Inlet and Outlet Air Ducts
- Approx. 100-150 kg
PRI-4050-M Primary Vacuum Table for alu and engineering plastics milling Trade Information
- 2500 Piece Per Month
- 10 Days
- All India
Product Description
ï¼›
2. It is recommended that the workpiece size be largerthan 100mm*100mm;
3. Suitable workpiece thickness: 140mm
4. Number and diameter of vacuum holes: 414 PCS of 12mm
5. No sealing rope required;
6. Allows for partial complete milling of the workpiece;
7. Employs an aluminum replacement plate design, allowingfor multiple overhauls of the clamping surface;
8. Primarily used for high-precision machining ofnon-ferrous metals; not suitable for graphite, fiberglass, or similarmaterials;
9. Machining accuracy can reach 0.02mm（Aluminum-plastic composite replacement plate mode）;
10. Allow the use of cutting fluid;
11. The suction force on the workpiece is the same ineach vacuum hole.
12. High-precision vacuum table with three clampingworking surfaces;
Distinct Advantages and Features of PRI-4050-M Vacuum Table
A replaceable protective plate fullyprotects the vacuum table main unit from damage. The protective plate isreplaceable and is a low-cost consumable. The soft clamping surface of thevacuum table main unit can also be used as an emergency clamping surface. Thesoft clamping surface of the main unit can accommodate workpieces with poorflatness. Compared to traditional grid vacuum tables, this new automatic valvevacuum table can quickly complete clamping, and its advantages are even moreapparent for irregularly shaped workpieces. Localized after-sales service isprovided for Indian users.
Prompt Supply, Payment, and Samples for PRI-4050-M Primary Vacuum Table
1. 2. 3. 4. 5. Localized after-sales servicein India.
FAQ's of PRI-4050-M Primary Vacuum Table:
Q: How does the PRI-4050-M Primary Vacuum Table ensure efficient vacuum processing?
A: The vacuum table features an advanced vacuum clamping system and It can accommodate the clamping of irregularly shaped thin sheet workpieces, does not require the installation of sealing ropes, and can complete clamping in a few seconds. Mainly used in CNC milling machines, engraving machines, and CNC machining centers.Q: What are the noise levels of the PRI-4050 during operation?
A: The vacuum table itself does not generate noise; rather, the vacuum pump that provides the vacuum source to the vacuum table will produce noise. The noise level of the vacuum pump is generally below 65 dB.Q: What are the primary applications of this vacuum table?
A: Mainly used in CNC milling machines, engraving machines, and CNC machining centers. Industries include: CNC precision machining, mold making,Q: When can I expect delivery of the PRI-4050 if I order now?
A: Most standard models are in stock. Please contact our account manager for details.Q: Where is the PRI-4050-M Primary Vacuum Table manufactured and supplied from?
A: There is only one factory in the world that manufactures the PRI-4050-M vacuum table, located in Chengdu, China. After an order is confirmed, the table is shipped from Chengdu to the customer's company in India via sea or air.Q: What are the size for workpiece used with PRI-4050-M vacuum table?
A: Generally, a minimum individual workpiece sizeof 100mm x 100mm is recommended. For smaller components (e.g., 50mm x50mm), we suggest using a "nesting" (tiling) strategy.Alternatively, auxiliary clamping methods such as adhesive wax or single-sidedadhesive tape can be used. Please contact the manufacturer for specificoperational techniques.Tell us about your requirement
